Balboa Spa Pack VS501

larger image

$485.00 $460.00
Save: 5% off

Balboa VS501z 5.5-1.5 Kw Digital Spa Pack
With Patented M7 technology - This is the world's best spa pack! - Made in America -

Time to upgrade your old spa pack hot tub heater?

Balboa VS501z, uses simply the best spa pack technology in the market. Completely digital circuitry means less failures, more accurate heating range, and much simpler to use. Accurate to +/- 1 degree with full top side LCD controllers, means, you will never have to leave the spas or tub to change the temperature.

The LCD controller is more costly than the LED styl VL401 controllers however it provides much better lumination durring the day. As such all our Spa Pack come standard with the upgrade to LCD controller.

The Balboa Spas Pack works at either 120 VAC producing 1.5KW, or with a change of a jumper operates at 230 VAC producing 5.5 KW of heat. It fits any standard 2" or 1 1/2" plumbing making it ideal to upgrade almost any older mechanical spa pack.

Replaces any Spa Pack from other manufactures! Don't be fooled, Balboa Spa Packs can replace any hot tub heater on the market including Gecko, Hot Springs, Len Gordon, Hydro Quip, LA Sas, Cal Spas, Coleman Spas, Beachcomber Spas, Artic Spas to name a few......

Built in programmable features such a cycle programming, sleep mode, economy mode and self diagnosis are just some of its features. Weather freeze ups are eliminated with the built in freeze protection system. It also has the ability to select how much current will be drawn allowing use of a 30 Amp breaker or 40 Amp, yet still deliver the full features.

It has receptacles for the following:

One 2-speed pump + one 1-speed pump or blower (not both)+ one circulation pump + one ozonator + one constant-on for Audio/Visual devices + one 12 volt light. All receptacles (except light) can be switched to supply 120 Volts or 230 Volts.

Comes complete with:

VS501Z pack including Stainless Steel portable heater with 2" heater tail pieces
4 button light duplex digital control
One 4-wire 2-speed pump cable with AMP plug
One 3-wire pump/blower cable with AMP plug
One 12 volt light wiring assembly with AMP plug
One loose 4-pin AMP plug with pins ( to adapt a non-Balboa ozonator)
Plasticized control instruction sheet; complete instruction manual for retrofit situations produced by Northern Lights.

The Patented M7 Technology removes the need for pressure sensors and remote heat sensors common on other older spa packs. This unique technology allows the spa pack to be positioned in any location or direction (before, after the pump or before or after the filter).

What is the difference between a regular VS501 and VS 501Z? Only the VS501(Z) is able to run either 220 VAC or 120 VAC accessories or a mixed combination! The latter & older models require accessories such as ozone to be the same voltage as the primary pump, limiting their applications. The VS501z is the most current model line from Balboa.

The LCD digital topside control includes light function, high low pump, temp control, and blower. Functions may be changed to Temp Up, Temp Down, Jets, and Light. The unit is backed by a 2 years manufacturer warranty that includes the heating element.

Specifications

10.56' High x 19.5' Long x 4.60' Deep

Comes with 12 V light that will support LED lighting

UL, CSA, and CE certification

Optional infrared water proof remote control is available ($125 extra)

120 or 220 VAC ozone support

120/240VAC @ 50/60 Hz

Pump 1= 12amp max; Pump 2= 12amp max; Blower= 8 amp max; Pump 1= 15 amp; Pump 2/Blower = 15 amp; Circulation Pump = 5 amp; Ozonator = 1 amp; A/V = 5 amp; Light = 12 v @ 1 amp

2 years manufacturer warranty

NOTE you can only use a 2nd single-speed pump or blower not both! If small circulating pump is being used the flow through heater must deliver 23 USGPM or more.

MADE IN AMERICA not China

If you are looking for the best most reliable tub replacement system on the market, then Balboa VS501z with M7 technology it is. Their unsurpassed reliability is why Balboa is the world leader in Spa Pack manufacturing both in quality and reliability.

Balboa Spa Pack Features

Features	VS501Z	VS520SZ	EL2001M3
5.5 Kw Heater 220 VAC	X	X	X
Separate Optional Aux 5.5 Kw Heater	X	X	X
240 VAC or 120 VAC	X	X	240 VAC
120/240 Volt output receptacle	X	X	X
Separate voltage for ozone & blower	common	common	X
2 -Speed Pump 1	X	X	X
1-Speed Pump 2		see note	X
2-Speed Pump 2		X	X
1-Speed Blower or Pump 3	X	X	X
Circulation Pump	X	X	X
Ozone	X	X	X
Audio Visual Equip	X	X	X
12 Volt Light	X	X	X
Light switchable to 12 volt or 120 VAC			X
Fiber Optic Wheel Light			X
Real Time Clock			X
Standard, Economy, Sleep Mode	X	X	X
12 hour filter cycle	X	X	X
24 hour filter cycle			X
Filter cycle program by time of day			X
Filter cycle increments			Fully Adjustable
Clean up cycle (filter & ozone on after use)			X
Ozone temp deactivation	only when jets are on	only when jets are on	X
Freeze Protection	X	X	X
Diagnostic messaging	X	X	X
IR Dolphin Remote Control Option (short range)	X	X	X
RF Station Wireless Remote Control (long range)			X
Wireless PC Remote Control via USB			X
Standard Topside	VL401	VL701S	ML700S
Optional Topside	VL403	VL700S	ML400S
*Cables provided*
1-speed 3 conductor Cables	1	2	2
2-speed 4 conductor Cables	1	2	2
12 Volt light wiring Kits	1	1	1
4-pin AMP connector	1	1	1
Tech Support 1 800 by NLCT	X	X	X
2 year Warranty	X	X	X

MOST IMPORTANT:

Our on-staff engineer means you get much more than just a quality product when you buy from us. Our engineer will help you before your purchase as well as during installation and will always be there for ongoing support afterwards, FREE OF CHARGE! Call us or email us and you will quickly see our difference!

Thank you for shopping Northern Lights Cedar Tubs! Call us anytime:
1 800 759 8990
